December 31, 2009

Horsehead and Flame, HaRGB combined (“MartinB method”)

After reading about MartinB’s method for combining Ha into/onto RGB data for his Cone nebula image a while back, I was itching to have a play with some of my own data.

Erik Larsen has very nicely allowed me to use his RGB data in this combined image, and to post the results. His data was 11x300s, taken with a modded Canon 500D through an Orion ED80. Many thanks for allowing me to show this.

So, I took Erik’s RGB Horsehead and Flame RGB data

and the Ha data that I took on Christmas Day

Threw them both into Registar, aligned the Ha data to the RGB data, saved them out.

Now using MartinB’s method, I load the RGB data into a layer, then duplicated that RGB layer on top with “soft light” mode. This increases the contrast, but also drops the black point, so I used some levels/curves to bring that back up a little.

I then pasted the greyscale Ha data into a layer on top, set the green and blue channels to black (only the red was left), then set that layer method to “lighten” to it only affected the reds.

After some careful levels and curves on the duplicate RGB and the Ha layers, it got somewhere close to what I wanted. The stars have a slight red halo from the larger Ha stars, which should be easy to fix later, and maybe I over did it with the Ha lightening 🙂

This is the result. Lots of lovely reds, but no loss of contrast like previous attempts of using just an additiona Ha layer, plus the other colours are not washed out. I am currently digging out all my previos Ha RGB images to see if I can improve on them with the same method.

(Click on image for larger version)

Posted by under Astronomy | Comments Off on Horsehead and Flame, HaRGB combined (“MartinB method”)

December 27, 2009

Horsehead/Flame on Christmas Day

95 days… ninety five long frustrating days… thats how long it was without an image. And then, on Christmas day, the skies cleared. It was glorious, and I have the imaging buzz again! Woohoo!

Mount: EQ6 via EQMOD
OTA: Borg 77EDII @ f/4.3
Guiding: SW ED80 + SX Lodestar + Maxim
Imaging: Starlight Xpress M25C + MaximDL, 8×900s, Astronomnik 13nm Ha (101 bias, 101 flats)
Orchestrated: CDD Commander
Stacked: DeepSkyStacker
Post Process: PSCS2 + PixInsight

(Click on the image for a larger version)

Posted by under Astronomy | Comments Off on Horsehead/Flame on Christmas Day

December 10, 2009

Rosette NGC 2237 in Ha(HaR)GB – Mixing Old and New data

80+ days now without any imaging is making me a bit crazy, so I decided to dig out some old data and see what I could do with it.

I took my old Rosette RGB data from January 2008, and used Registar to align that with Ha data from MartinB. Used the Ha data to lighten only the red channel of the RGB, and then used a deconvolved copy of the Ha data as a Luminance channel on top of all of it. Lots of fiddling with levels, curves, selective sharpening, layer masks and NoiseNinja before it started to look anywhere near right 🙂

I had forgotten about all the strange things that the Hyperstar did to my images, includuding being flipped horitonally (caused Registar to fail!) and slightly bloaty stars. Looking at this RGB data again now (nearly 2 years later), I can see some real issues with it. Hopefully I`ll get a chance to shoot some RGB data of the Rosette this winter with my Borg 77…. actually, at the current rate of bad weather, I`ll be happy if I manage to image anything at all before summer comes around again!

I`d just like to say that I have looked at this image on several different monitors, and it varies wildly from rich reds to light salmon pinks, so I just worked on it with my calibrated monitors for what I see as my own personal choice. Your own opinion of the colour will vary depending on how your monitor shows it.

I`d also like to thank MartinB for allowing me to use his Ha data for this project, it really helped add some punch to this image.

RGB Data
OTA: NexStar 8 GPS + Hyperstar @ f/2
Guiding: WO66 + DSI-C + PHD
Imaging: QHY8 + MaximDL, 20x180s, Astronomik CLS
Stacked: DeepSkyStacker

HA Data
OTA: FSQ 106
Imaging: QSI 532 + MaximDL, 14x600s, Astronomik 13nm Ha
Stacked: CCDStack

Aligned with Registar, post process with PixInsight and PSCS2.

(Click on Image for larger version)

Posted by under Astronomy | Comments Off on Rosette NGC 2237 in Ha(HaR)GB – Mixing Old and New data
